Epson Lifestudio Grand EH-LS670B 4K PRO-UHD Laser Projection TV

Bersiaplah terkagum

Whether you're watching live sports, gaming on the latest generation of consoles, or streaming your favourite movie, the Epson LifeStudio Grand EH-LS670B delivers an epic big screen experience that will simply amaze you. With 4K PRO-UHD¹ resolution, a screen size of up to 120", Google TV^TM² function, and Sound by Bose, the EH-LS670B opens up your possibilities to create the ultimate home cinematic setting.

Stunning 4K PRO-UHD¹ picture
Immersive display
Ultra Short Throw Laser Projection Technology
Powered by Google TV^{TM 2}
Sound by BOSE
3,600 lumens of color and white brightness³
10-bit HDR Color Processing
Bluetooth Speaker Mode

Find Accessories

Overview

Advanced 3LCD technology and Laser Light Source
Epson's original 3LCD technology and advanced laser light source deliver exceptionally bright and clear images, even in well-lit environments, ensuring high image quality that stays true to life. It offers a cinematic experience so immersive, it feels as if you're right there in the scene.

Immersive big screen size up to 120 inch
With Epson's ultra-short-throw lens, the EH-LS670B can be placed close to the wall while projecting images up to 120 inches in size, creating an immersive viewing experience. Paired with Sound by Bose, it delivers room-filling audio with rich detail and deep bass.

Sound By BOSE
Enjoy impactful audio that fills the room with Sound by Bose technology. The custom-designed stereo system creates audio you can feel, delivering rich, balanced sound with deep bass, pulling you and everyone around you, right into the action. We can’t wait for you to hear it.

Upgraded entertainment with Google TV ^{TM 2}
The EH-LS670B comes with Google TV ^{TM 2} operating system and in-built Google Cast, along with a simple-to-use remote including voice search with built-in Google Assistant. Watch all your favorite streaming channels including YouTube, Netflix, and more. The experience is truly epic.

Easy setup
User can easily correct any distortion using the Epson Setting Assistant (ESA) app.

Specifications

Projection Technology:

Projection Technology: RGB liquid crystal shutter projection system

Specifications of Main Parts:

LCD: Size: 0.62-inch
Resolution: 4K PRO-UHD¹Light Source: Tipe: Laser Diode 41,9 mW (Output)
Mode Hidup: Hingga 20.000 jam (Mode Ramah Lingkungan) ^*2Projection Lens: Type: No Optical zoom / Focus (Manual)
F-Number: 1.60
Focal Length: 3.7mm
Zoom Ratio: 1-2.5 (Digital zoom)
Throw Ratio: 0.25 - 0.62 (Digital zoom)

Screen Size (Projected Distance):

Zoom : Wide: 60 " to 120 " [32.5cm to 70.3cm] @ 16:9Zoom : Tele: N/AStandard Size: 77.0" screen 43.3 cm

Brightness:

Colour Light Output: 1500 lumens ^*1White Light Output: 1500 lumens ^*1

Geometric Correction:

Point Correction: YesQuick Corner: Yes

Konektivitas:

Jaringan: Wired LAN: N/A
Wireless: Built-in (Smart Media Player)Digital Input: HDMI: 3 (SMF, HDMI2=eARC, HDCP 2.3)Audio Out: 1 (Headphone)
1 (S/PDIF)Others: 2 HDMI (1 HDMI HDCP2,2), 1 RS-232c, 1 RCA (komposit), 3 RCA (komponen), 1VGA sub-15 pin 15 (Input komputer), 1 LAN Kabel (RJ45, 100 Mbps) hanya untuk komando dan kontrol, 1 USB Tipe Mini B (untuk layanan dan pembaruan Firmware), 2 pemicu keluar jack mini 3,5 mm USB I/O: USB Type A: 2
USB Type B: 1

Daya:

Konsumsi Daya: 220 – 240V
Laser NYALA: 442W, Laser NYALA (Ramah Lingkungan): 262W
Komunikasi Siaga NYALA: 2,3W/Mati: 0,34W Power Supply Voltage: 100 – 240V AC ± 10%, 50/60 Hz

Operating Altitude:

Operating Altitude: Over 1500m / 4921 ft with High Altitude Mode: 0 to 3048m (0ft to 10,000ft)

Start-Up Period:

Start-Up Period: Less than 7.1 sec (until EPSON logo display) Suspend Mode: Less than 7.1 sec (unitil source image display)Warm-Up Period: 30 seconds

Cool Down Period:

Cool Down Period: Instant off

Dimension Excluding Feet (W x H x D):

Dimension Excluding Feet (W x H x D): 467 x 133 x 400mm

Weight:

Berat: 18Kg

Fan Noise:

Fan Noise (Normal / Eco): 19 dB (Peningkatan 4K: Tidak Aktif)

Projection Lens:

Type: Zoom Optik Bertenaga/Fokus Bertenaga Focal Length: 21.3 mm – 44.7 mm Zoom Ratio: 1 – 2.1 F-number: 2.5 – 3.7 Lens Shift: Vertikal: 90% Maksimum (atas dan bawah dengan horizontal terpusat)
Horizontal: Maksimum 40% (Kiri dan Kanan denganVertikal terpusat)Lens Cover: Berdaya, rana lensa geser

Adjustment Functions:

Aspect Mode: Otomatis/Normal/Penuh/Zoom/Lebar Anamorfik/Perkecil HorizontalFrame Interpolation: Mati/Rendah/Normal/Tinggi (Mode 2D dan 3D)Colour Mode: Dynamic, Standard, Cinema, NaturalScene Adaptive Gamma: Yes (Off, Low, Medium, Strong)

Image Enhancement:

Super Resolution: Mati / 1 / 2 / 3 / 4 / 5

Operating Temperature:

Operating Temperature: 0m / 0ft to 2286m / 7500ft (Low Altitude): 5 °C to 35 °C <41 °F to 95 °F>
Over 2286m / 7500ft (High Altitude): 5°C to 30 °C <41 °F to 86 °F>
20% - 80% humidity/No condensation

Internal Speaker(s):

Sound Output: 2.1ch Satellite x2, Woofer x1 (Sound by BOSE)

Dimension Excluding Feet:

Dimension Excluding Feet (D x W x H): 553mm x 550mm × 225mm

Brightness:

Colour Light Output: 3,600 ImWhite Light Output (Normal/Quiet): 3,600 Im / 1,800 lm

Power Supply Voltage:

Power Supply Voltage: 100 - 240 V AC ±10%, 50/60 Hz

Power Consumption (220-240V):

Lamp On (Normal / Low*) : 254 / 162WNetworked Standby: On: 2.0WEnergy Saving: Off: 0.5W

Fan Noise (Normal / Eco):

Fan Noise (Normal / Eco): 29dB / 20dB

Wireless Specifications (Smart Media Player):

Wi-Fi generation name: Wi-Fi 6Supported Standards and Frequency: IEEE 802.11a (5 GHz),
IEEE 802.11b (2.4 GHz),
IEEE 802.11g (2.4 GHz),
IEEE 802.11n (2.4 GHz and 5 GHz),
IEEE 802.11ac (5 GHz),
IEEE 802.11ax (2.4 GHz, 5 GHz,and 6GHz)Supported Security Type: WFA WPA/WPA2/WPA3 personal, WPS2.0, WAPI

Resolution on Screen (Max):

Resolution: 4k Enhancement¹Jumlah Pixel: 4,147,200 dots (1920 x 1080 x 2)Contrast Ratio: Over 5,000,000:1

See Full Specs Hide Full Specs

Print All Specs

Accessories

Aksesori

Air Filters

Screens

Notes:

¹ 4K Enhancement Technology shifts each pixel to produce an image on screen, up to the stated specification.

² Google, Google Play, YouTube, Android TV and other marks are trademarks of Google LLC. Google Assistant is not available in certain languages and countries. Availability of services varies by country and language. Requires wireless network connection of 5 Mbps or faster. Some apps require paid subscriptions.

³ Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.

^* where Low=Eco/Extended/Quiet, whichever lower
