Epson EpiqVision Mini EF-11 Laser Projection TV

Product Models displayed on this website may be available in certain regions only.

Experience A New Type of Projection Experience

Go Epic!

Enjoy an epic viewing experience virtually anywhere with the Epson EpiqVision Mini EF-11 Laser Projection TV. With a built-in high-quality speaker system, this all-in-one projector is the perfect way to watch all your favorite content. Simply connect your entertainment devices using the HDMI port and you’re ready to project your favorite content up to an epic 150" — no screen required.

The Epson EpiqVision Mini EF-11 Laser Projection TV takes the complexity out of watching your favorite content anywhere in your home.

  • Full HD 1080p resolution
  • Stunning Picture Quality up to 150"
  • Screen Mirroring from smart devices1
  • Integrated Dual-Speaker Audio System
  • Lightweight of up to 1.2kg
  • 20,000 Hours Laser Light Source Technology



Low maintenance cost
With 20,000 hours of laser light source life, EpiqVision Laser Projection TV practically have little to no maintenance costs2 while you enjoy more than 10 years of entertainment3.




Quick start-up
With the short start-up time needed for EpiqVision Laser Projection TV, start watching the latest movies and catch up on your favorite shows without further wait and hassle.




Sleek and compact
With a weight as light as 1.2Kg, the EpiqVision Mini EF-11 Laser Projection TV is easy to carry around and blends in well with any environment due to its sleek design.




Smart devices-ready
With built-in screen mirroring function, you can easily cast movies, shows and photos from your smart devices.


Projection Technology:


Projection Technology: RGB liquid crystal shutter projection system (3LCD)

Specifications of Main Parts:


LCD: Panel Size: 0.62 inchLightsource: Life (Normal / Extended): 20,000 hours
Type: Laser DiodeProjection Lens: F-Number: 2.0
Type: No optical zoom / Focus: (Manual)
Zoom Ratio: EF-11: 1.0 – 1.35 (Digital Zoom)
Focal Length: 13.90 mm
Throw Ratio: 1 (Wide to tele)
Aspect Ratio: 16:9Native Resolution: Full HD (1080p)

Brightness:


White Light Output (Normal / Eco): 1,000 lm / 1,000 lm
1,000 lm / 1,000 lm

Connectivity:


USB Interface: USB Type A: 1 ( For Firmware Update & Copy of OSD and power supply)
USB Type B: 1 (For Firmware Update and Copy OSD Settings)Digital Input: HDMI: 1 (HDCP1.4)Audio Out: Stereo mini jack: 1 (for headphone)

Contrast Ratio:


Contrast Ratio: Over 2,500,000:1

Screen Size (Projected Distance):


Standard Size: 60” screen @ 1.33 mZoom : Wide: 30” to 150” [0.65 to 3.38m]Zoom : Tele: 22" to 111" [0.65 - 3.38m]

Geometric Correction:


Vertical/Horizontal Keystone: ±34O / ±40OAuto Keystone: Yes (vertical only) ±34O (V)Quick Corner: YesProjection Orientation: 360O

Dimension Excluding Feet (W x H x D):


Dimension Excluding Feet (W x H x D): 175 X 175 X 58 mm

Internal Speaker(s):


Sound Output: 1.5W 2 Way (Mono)

Weight:


Weight: Approx. 1.2 Kg

Projectors Facets:


Resolution, Projectors Facets: 1080pContrast Ratio, Projectors Facets: Over 2,500,000:1Brightness Range Lumens, Projectors Facets: 10004K PRO-UHD, Projectors Facets: NoFeatures, Projectors Facets: Screen mirroringLaser / Lamp, Projectors Facets: LaserScreen Size, Projectors Facets: 20 - 150Projector Primary Usage, Projectors Facets: Home EntertainmentProjector Series, Projectors Facets: EpiqVision Mini

Notes:

1 Requires wireless network connection of 5 Mbps or faster. Some apps require paid subscriptions.

2 No required maintenance for the light source for up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 - 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period.

3 10 years calculated based on 3.15 hours usage per day.
